Well-designed 2023 Dechuang Electromagnetic Coil Power Relay DC 12V 24V / AC 110V 220V 8 Pin Micro Mini Relay with Socket Base Relays

Short Description:

Introducing the Taihua JQX-63F, a high-quality big power relay designed to deliver exceptional performance and reliability in demanding electrical applications. With its robust construction and impressive power handling capabilities, this relay is the ideal choice for industrial and commercial use, offering both 80A and 100A variants to suit a wide range of power requirements.

The JQX-63F relay is engineered to excel under high current and voltage conditions, ensuring stable and efficient operation in challenging environments. Its durable design and premium-grade materials enable it to withstand heavy electrical loads, making it a trusted solution for critical applications where reliability is paramount.

Equipped with advanced features such as low power consumption and minimal electromagnetic interference, this relay provides precise and responsive control over electrical circuits. Its quick response time and high switching capacity make it well-suited for controlling motors, lighting systems, heating elements, and other power-intensive devices.

Designed for easy installation and maintenance, the JQX-63F relay offers a user-friendly solution for integrating high-power switching capabilities into diverse systems. Its compact size and versatile mounting options further enhance its suitability for a variety of applications, from industrial machinery to energy management systems.

In summary, the Taihua JQX-63F 80A and 100A models represent a top-tier choice for engineers and designers seeking a dependable, high-performance solution for managing heavy electrical loads. With its durable design, advanced features, and broad applicability, this relay sets a new standard for power switching reliability and efficiency.

Send email to us

Product Detail

FAQ

Product Tags

We insist on offering good quality generation with very good business enterprise concept, honest income as well as best and fast assistance. it will bring you not only the premium quality product or service and huge profit, but probably the most significant is usually to occupy the endless market for Well-designed 2023 Dechuang Electromagnetic Coil Power Relay DC 12V 24V / AC 110V 220V 8 Pin Micro Mini Relay with Socket Base Relays, With excellent services and good quality, and an enterprise of foreign trade featuring validity and competitiveness, that can be trusted and welcomed by its customers and generates happiness to its staff.
We insist on offering good quality generation with very good business enterprise concept, honest income as well as best and fast assistance. it will bring you not only the premium quality product or service and huge profit, but probably the most significant is usually to occupy the endless market for China Industrial Pin Relay and Industrial Motor Relay, Our business activities and processes are engineered to make sure our customers have access to widest range of goods with the shortest supply time lines. This achievement is made possible by our highly skilled and experienced team. We look for people who want to grow with us around the globe and stand out from the crowd. We’ve got people who embrace tomorrow, have vision, love stretching their minds and heading far beyond what they thought was achievable.

Contact Ratings
Contact Ratings	1Z,1H,1D
Contact Resistance	100MΩ(1A 6VDC)
Contact Material	AgCdO
Contact Capacity	60A 250VAC/30VDC
Specification
Insulation Resistance	1000MΩ,500VDC
Dieletric Strength	BCC 2500V 1 min
Dieletric Strength	BOC 1200V 1 min
Operate Time	25ms/25ms
Terminal Type	Screw
Coil Ratings
Norminal Coil Power	DC:2.0W AC:2.5VA

Coil Versions
Nominal Voltage VDC	Pull-in Voltage VDC	Release Voltage VDC	Coil Resistance Ω:±10%	Nominal Voltage VAC	Pull-in Voltage VAC	Release Voltage VAC	Coil Resistance Ω:±10%
6	4.80	0.60	20	6	4.80	1.80	14.4
12	9.60	1.20	45	12	9.60	3.60	57
24	19.2	2.40	320	24	19.20	7.20	250
48	38.4	4.80	1280	48	38.40	14.4	921
60	48.0	6.00	2800	110	88.00	36.0	5000
110	88.0	11.0	9650	220/240	176.0	72.0	19600/25040

We insist on offering good quality generation with very good business enterprise concept, honest income as well as best and fast assistance. it will bring you not only the premium quality product or service and huge profit, but probably the most significant is usually to occupy the endless market for Well-designed 2023 Dechuang Electromagnetic Coil Power Relay DC 12V 24V / AC 110V 220V 8 Pin Micro Mini Relay with Socket Base Relays, With excellent services and good quality, and an enterprise of foreign trade featuring validity and competitiveness, that can be trusted and welcomed by its customers and generates happiness to its staff.
Well-designed China Industrial Pin Relay and Industrial Motor Relay, Our business activities and processes are engineered to make sure our customers have access to widest range of goods with the shortest supply time lines. This achievement is made possible by our highly skilled and experienced team. We look for people who want to grow with us around the globe and stand out from the crowd. We’ve got people who embrace tomorrow, have vision, love stretching their minds and heading far beyond what they thought was achievable.
