Introducing the Taihua JQX-63F, a high-quality big power relay designed to deliver exceptional performance and reliability in demanding electrical applications. With its robust construction and impressive power handling capabilities, this relay is the ideal choice for industrial and commercial use, offering both 80A and 100A variants to suit a wide range of power requirements.

The JQX-63F relay is engineered to excel under high current and voltage conditions, ensuring stable and efficient operation in challenging environments. Its durable design and premium-grade materials enable it to withstand heavy electrical loads, making it a trusted solution for critical applications where reliability is paramount.

Equipped with advanced features such as low power consumption and minimal electromagnetic interference, this relay provides precise and responsive control over electrical circuits. Its quick response time and high switching capacity make it well-suited for controlling motors, lighting systems, heating elements, and other power-intensive devices.

Designed for easy installation and maintenance, the JQX-63F relay offers a user-friendly solution for integrating high-power switching capabilities into diverse systems. Its compact size and versatile mounting options further enhance its suitability for a variety of applications, from industrial machinery to energy management systems.

In summary, the Taihua JQX-63F 80A and 100A models represent a top-tier choice for engineers and designers seeking a dependable, high-performance solution for managing heavy electrical loads. With its durable design, advanced features, and broad applicability, this relay sets a new standard for power switching reliability and efficiency.

Send email to us

Product Detail

FAQ

Product Tags

Fast and very good quotations, informed advisers to help you choose the correct merchandise that suits all your preferences, a short creation time, responsible excellent command and different companies for paying and shipping affairs for Cheap price Keyong Kqi15 (115F) Relay 5-48VDC Relay Power Relay, Our tenet is “Reasonable costs, successful manufacturing time and finest service” We hope to cooperate with much more customers for mutual growth and rewards.
Fast and very good quotations, informed advisers to help you choose the correct merchandise that suits all your preferences, a short creation time, responsible excellent command and different companies for paying and shipping affairs for Relay and Relay Contactor, Our solutions have national accreditation requirements for qualified, good quality goods, affordable value, was welcomed by individuals all over the world. Our products will continue to improve inside the order and appear forward to cooperation with you, Genuinely must any of individuals goods be of interest to you, make sure you letus know. We will be satisfied to provide you a quotation up on receipt of the comprehensive needs.

Contact Ratings
Contact Ratings	1Z,1H,1D
Contact Resistance	100MΩ(1A 6VDC)
Contact Material	AgCdO
Contact Capacity	60A 250VAC/30VDC
Specification
Insulation Resistance	1000MΩ,500VDC
Dieletric Strength	BCC 2500V 1 min
Dieletric Strength	BOC 1200V 1 min
Operate Time	25ms/25ms
Terminal Type	Screw
Coil Ratings
Norminal Coil Power	DC:2.0W AC:2.5VA

Coil Versions
NominalVoltage VDC	Pull-inVoltage VDC	ReleaseVoltage VDC	CoilResistance Ω:±10%	NominalVoltage VAC	Pull-inVoltage VAC	ReleaseVoltage VAC	CoilResistance Ω:±10%
6	4.80	0.60	20	6	4.80	1.80	14.4
12	9.60	1.20	45	12	9.60	3.60	57
24	19.2	2.40	320	24	19.20	7.20	250
48	38.4	4.80	1280	48	38.40	14.4	921
60	48.0	6.00	2800	110	88.00	36.0	5000
110	88.0	11.0	9650	220/240	176.0	72.0	19600/25040
